Model DFGD518 Electric Supply voltage 400V / 3N ph / 50Hz Convertible to 230V / 1+N / 50Hz ; 230V / 3phase / 50Hz Dafault installed power* 9.9 kW Reducible installed power* 6.9 kW Boiler heating elements power* 9 kW Boiler reducible to* 6 kW Tank heating elements 3 kW Wash pump size 0.8 kW Water Water supply temperature 10-65°C Water supply hardness (max) 14°fH (8°dH) Inlet water supply pressure 0.5-7 bar Water consumption per cycle 2L Boiler capacity 12L Tank capacity 24L Incoming water line size G 3/4" Drain line size 20.5mm Key Information N° of cycles 3 Duration cycle - High productivity* 45/84/150 sec Duration cycle - ETL Sanitation* 57/84/150 sec Racks per hour - High productivity* 80 Racks per hour - ETL Sanitation* 63 Dishes per hour - High productivity* 1440 Dishes per hour - ETL Sanitation* 1134 Wash temperature - High productivity 55-65°C Wash temperature - ETL Sanitation 75°C (min) Rinse temperature (min) 84°C Noise level <63 dBA External dimension (L x W x H) 752 x 755 x 1567mm Net weight 117 kg Packing size (L x W x H) 667 x 775 x 1567mm Shipping weight 129 kg
